The Kona Storm monitor system is characterized by the impressive dynamic response of the transient. It is possible to manage the three transducers of the Kona Storm 6.2 through the passive crossover by a single amplification channel. Otherwise is possible to switch off the 12” woofer to made a 2 active lines speaker. The head easily supports in power the presence of two 18 "5.1 ovoidal subwoofers for each channel, obtaining performances at very high sound pressure.
TYPE Three way passive horn loaded with extended low frequency direct emission component
FREQUENCY RESPONSE 100 Hz - 18 KHz
TOTAL SENSITIVITY 100 dB 1W/m with passive crossover
100 dB 1W/m for mid-high
LOW FREQUENCIES 12” Low woofer 8 Ohm 400 W nominal 800 W peak
MEDIUM FREQUENCIES 2” (50 mm) MF compression driver 8 Ohm 80 W nominal 160 W peak
HIGH FREQUENCIES 1” (25 mm) HF compression driver 8 Ohm 70 W nominal 140 W peak
NOMINAL IMPEDANCE 4 Ohm with three way passive crossover
POWER HANDLING 1000 W 4 Ohm with amplifier, 2 Ohm stable
MANAGE 2 Ch amplifier to a couple of Kona loudspeakers (passive crossover inside, for each
Kona)+DSP to match to subwoofer. High-pass filter @100Hz, 24 dB/oct. LR
RECOMMENDED AMPLIFIER Full Fatt Audio FFA 6000 with external DSP to match to subwoofer
DISPERSION 60° horizzontal, 60° vertical
CONSTRUCTION MATERIALS Fiber-reinforced composite, stainless steel
FINISH all ral color and texture on order
PROTECTIVE GRILLES Kona is usually sold with this grid in stainless steel to protect the 12” mid bass,as standard
CONNECTORS 1x Neutrik NL4 or custom preference
DIMENSIONS
(without support)
(W) 472 mm (H) 918 mm (D) 420 mm
(W) 18,5 inch (H) 36 inch (D) 16,5 inch
WEIGHT 23 Kg (51 lb)
