Product Description
Expand Production Possibilities and Revolutionize Workflow with Next-Generation 1-Chip DLP 4K Projectors.
Specifications |
|||
| Projector type | 1-Chip DLP™ projector | ||
| Light output | 12,000lm/12,400 lm (Center) | ||
| Resolution | 4K (3840 x 2400 pixels) | ||
| Contrast ratio | 25,000:1 (Full On/Full Off, Dynamic Contrast [3] | ||
| Refresh Rate | 240 Hz Refresh rate varies depending on scanning frequency. | ||
| Terminals | 2 x HDMI In 1 x Display Port In 1 x LAN: RJ-45 1 x RS232: DB-9pin (Serial In) 1 x RS232: DB-9pin (Serial Out) 1 x RS232: DB-9pin (Remote In) 1 x USB (DC Out) 1 x USB (for AJ-WM50 Series) 1 x Mini Jacks (Remote In) 1 x Mini Jacks (Remote Out) 1 x BNC In(Multi Projector Sync) 1 x BNC Out(Multi Projector Sync) 1 x Available Slots for Interface Boards | ||
| Dimensions (W x H x D) | 498 x 212 x 648 mm | ||
| Weight | Approx. 28.7 kg | ||
| Operation noise | 38dB (Normal), 35dB (Quiet Mode) | ||
| Max Power Consumption | 1,030 W (10.4–4.3 A) (1,040 VA) | ||
| Supplied Accessories | Power cord (x 1) (x 2 for Europe / ASIA models) Wireless/wired remote control unit (x 1) Batteries for remote control (AAA/R03 or AAA/LR03 battery x 2) SLOT adapter (x 1) *** Lens is included on “L” models with Throw Ratio 1.36-2.10:1 | ||
Optional Accessories |
|||
| Lens | Zoom lens | ET-C1U100 (0.308-0.330:1) | |
| Lens | Zoom lens | ET-C1U200 (0.380:1) | |
| Lens | Zoom lens | ET-C1W300 (0.550-0.690:1) | |
| Lens | Zoom lens | ET-C1W400 (0.680-0.950:1) | |
| Lens | Zoom lens | ET-C1W500 (0.940-1.39:1) | |
| Lens | Zoom lens | ET-C1S600 (1.36-2.10:1) | |
| Lens | Zoom lens | ET-C1T700 (2.07-3.38:1) | |
| Lens | Zoom lens | ET-C1T800 (3.3-6.6:1) | |
| Ceiling Mount Bracket | with 6-axis adjustment for high ceilings | ET-PKD130H | |
| Ceiling Mount Bracket | for high ceilings | ET-PKD120H | |
| Ceiling Mount Bracket | for low ceiling | ET-PKD120S | |
| Attachment for Ceiling Mount Bracket | ET-PKD130B | ||
| Function Board | 12G-SDI Terminal Board | TY-SB01QS | |
| Function Board | 12G-SDI Optical Function Board | TY-SB01FB | |
| Function Board | DIGITAL LINK Terminal Board | TY-SB01DL | |
| Function Board | Wireless Presentation System Receiver Board | TY-SB01WP | |
| DIGITAL LINK Switcher | |||
